DIN 2631 PN6 Weld Neck Flanges Manufacturer and Supplier In Abuja, Nigeria

In the bustling industrial landscape of Abuja, Kabby Flanges stands as a trusted partner for robust piping solutions. We specialize in supplying and manufacturing high-quality DIN 2631 PN6 Weld Neck Flanges, engineered to meet the rigorous demands of various sectors. Our commitment is to provide local industries with reliable components that ensure seamless and secure connections, supporting the infrastructure and projects that drive our region forward with dependable performance you can count on every single day.

DIN 2631 PN6 Standards Weld Neck Flanges in Abuja, DIN 2631 PN6 Weld Neck Plate Flange in Lagos, Raised Face DIN 2631 PN6 WNRF Flanges in Port Harcourt, Stainless Steel DIN 2631 PN6 Weld Neck Flanges in Kano, DIN 2631 PN6 Welding Neck Pipe Flange in Ibadan, Best Price of DIN 2631 PN6 Weld Neck Flange Manufacturer in Nigeria.

Stainless Steel DIN 2631 PN6 Weld Neck Flanges

Alloy Steel DIN 2631 PN6 Weld Neck Flanges

Alloy 20 DIN 2631 PN6 Weld Neck Flanges

Crafted to exacting standards, these flanges are typically produced from durable carbon steel, ensuring excellent strength and longevity. Their composition is carefully controlled to deliver superior mechanical properties, including high tensile strength and good yield strength, which allow them to handle significant pressure loads. This robust construction makes them perfectly suited for the demanding operating conditions specified by the PN6 pressure rating, providing a reliable and long-lasting solution for critical pipeline connections.

Monel DIN 2631 PN6 WNRF Flange in Nigeria, Hastelloy DIN 2631 PN6 Weld Neck Flanges in Abuja, Titanium DIN 2631 PN6 Welding Neck Flanges in Ibadan, SS DIN 2631 PN6 Weld Neck Flanges Stockist in Lagos, Nickel Alloy DIN 2631 PN6 Weld Neck Flanges in Port Harcourt, Inconel DIN 2631 PN6 WNRF Flanges in Kano, Alloy Steel DIN 2631 PN6 Weld Neck Flanges, Duplex Steel DIN 2631 Weld Neck Flange, Carbon Steel DIN 2631 PN6 Welding Neck Flanges in Nigeria.

DIN 2631 PN6 Weld Neck Flanges Specification

Size Chart	1/2″ (15 NB) To 48″ (1200NB)
Coating Flanges Faces	Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint
Design For Size	DIN, EN, ASA, PN, JIS, BS, ANSI, ASME
Pressure Rating Table	Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS
Supporting Flanges Material	Flanges Bolts, Gasket, Ring Joint
Connect Type Type	FF, RTJ, SMF, LMF, RF, LJF
Production Process	Forged, Heat Treated and Machined
Standard	ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange
Machining Equipment	Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc

DIN 2631 PN6 Weld Neck Flange Dimensions

Pipe			Flange				Neck				Raised face		Screws			Weight
Pipe			Flange				Neck				Raised face		Screws			(7,85 Kg/dm3)
Rated	d1		D	b	k	h1	d3	s	r	h2	d4	f	Holes	Thread	d2	Kg
Diameter	ISO Series	DIN Series	D	b	k	h1	d3	s	r	h2	d4	f	Holes	Thread	d2	Kg
15	–	20	80	12	55	30	28	2	4	6	40	2	4	M 10	11	0,392
15	21,3	–	80	12	55	30	30	2	4	6	40	2	4	M 10	11	0,392
20	–	25	90	14	65	32	35	2,3	4	6	50	2	4	M 10	11	0,592
20	26,9	–	90	14	65	32	38	2,3	4	6	50	2	4	M 10	11	0,592
25	–	30	100	14	75	35	40	2,6	4	6	60	2	4	M 10	11	0,747
25	33,7	–	100	14	75	35	42	2,6	4	6	60	2	4	M 10	11	0,747
32	–	38	120	14	90	35	50	2,6	6	6	70	2	4	M 12	14	1,05
32	42,4	–	120	14	90	35	55	2,6	6	6	70	2	4	M 12	14	1,05
40	–	44,5	130	14	100	38	58	2,6	6	7	80	3	4	M 12	14	1,18
40	48,3	–	130	14	100	38	62	2,6	6	7	80	3	4	M 12	14	1,18
50	–	57	140	14	110	38	70	2,9	6	8	90	3	4	M 12	14	1,34
50	60,3	–	140	14	110	38	74	2,9	6	8	90	3	4	M 12	14	1,34
65	76,1	–	160	14	130	38	88	2,9	6	9	110	3	4	M 12	14	1,67
80	88,9	–	190	16	150	42	102	3,2	8	10	128	3	4	M 16	18	2,71
100	–	108	210	16	170	45	122	3,6	8	10	148	3	4	M 16	18	3,24
100	114,3		210	16	170	45	130	3,6	8	10	148	3	4	M 16	18	3,24
125	–	133	240	18	200	48	148	4	8	10	178	3	8	M 16	18	4,49
125	139,7	–	240	18	200	48	155	4	8	10	178	3	8	M 16	18	4,49
150	–	159	265	18	225	48	172	4,5	10	12	202	3	8	M 16	18	5,15
150	168,3	–	265	18	225	48	184	4,5	10	12	202	3	8	M 16	18	5,15
200	219,1	–	320	20	280	55	236	5,9	10	15	258	3	8	M 16	18	7,78
250	–	267	375	22	335	60	282	6,3	12	15	312	3	12	M 16	18	10,8
250	273	–	375	22	335	60	290	6,3	12	15	312	3	12	M 16	18	10,8
300	323,9	–	440	22	395	62	342	7,1	15	15	365	4	12	M 20	22	14
350	355,6	–	490	22	445	62	385	7,1	12	15	415	4	12	M 20	22	18,5
350	–	368	490	22	445	62	385	7,1	12	15	415	4	12	M 20	22	16,7
400	406,4	–	540	22	495	65	438	7,1	12	15	465	4	16	M 20	22	21,2
400	–	419	540	22	495	65	438	7,1	12	15	465	4	16	M 20	22	19
500	508	–	645	24	600	68	538	7,1	12	15	570	4	20	M 20	22	28,6
600	610	–	755	24	705	70	640	7,1	12	16	670	5	20	M 24	26	31,5
700	711	–	860	24	810	70	740	7,1	12	16	775	5	24	M 24	26	37,4
800	813	–	975	24	920	70	842	7,1	12	16	880	5	24	M 27	30	46,1
900	914	–	1075	26	1020	70	942	7,1	12	16	980	5	24	M 27	30	55,6
1000	1016	–	1175	26	1120	70	1045	7,1	16	16	1080	5	28	M 27	30	61,9

Largest DIN 2631 PN6 Weld Neck Flanges Supplier in Abuja, Nigeria

Kabby Flanges, a leading supplier in Abuja, Nigeria, offers an extensive selection of DIN 2631 PN6 Weld Neck Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.

Contact us to get a quick quote for your requirement.

We offer These Flanges as per DIN, ISO, JIS or ANSI Standard.

DIN 2631 PN6 Weld Neck Flanges are primarily used in low-pressure piping systems across industries such as oil and gas, petrochemical, water treatment, and HVAC. Their design allows for secure, leak-proof connections and minimizes stress at the base, making them ideal for systems where temperature and pressure may fluctuate mildly. These flanges are commonly installed in pipelines, pumps, and valves, providing stability and alignment. Their durability and precise fit make them essential for ensuring efficient flow and system integrity in low-pressure applications.

DIN 2631 PN6 Welding Neck Flanges Stockist in Ibadan, DIN 2631 PN6 Weld Neck Flanges Supplier in Lagos, DIN 2631 PN6 Weld Neck Flanges Supplier in Abuja, DIN 2631 PN6 Welding Neck Flanges Stockist in Nigeria, DIN 2631 PN6 Weld Neck Flanges Manufacturer in MM, DIN 2631 PN6 WNRF Flanges Manufacturer in Nigeria.

Types of DIN 2631 PN6 Weld Neck Flanges

Are Custom Sizes Available for DIN 2631 PN6 Weld Neck Flanges?

Yes, we offer custom sizes for DIN 2631 PN6 Weld Neck Flanges to meet specific project needs. Our team at Kabby Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@kabbyflanges.com.

DIN 2631 PN6 Weld Neck Plate Flange Size Chart

NPS NPS (inch)
NPS NPS (inch)	Diammeter of Flange (inch)	No. of Bolts	Diammeter of Bolts (inch)	Diammeter of Bolt Holes (inch)	Bolt Circle (inch)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Widest Range of DIN 2631 PN6 Weld Neck Flanges in Nigeria.

Nickel Alloy DIN 2631 PN6 Welding Neck Flange	Mild Steel DIN 2631 PN6 Weld Neck Flange
Carbon Steel DIN 2631 PN6 Welding Neck Flange	DIN 2631 PN6 Weld Neck RF Flange Supplier in Nigeria
DIN 2631 PN6 Weld Neck Flange Dimensions	Raised Face DIN 2631 PN6 Weld Neck Flange Manufacturer
18 inch DIN 2631 PN6 Carbon Steel Weld Neck Flange	DIN 2631 PN6 Weld Neck Flange Dimensions in mm
Alloy Steel DIN 2631 PN6 Welding Neck Flanges	Copper Nickel DIN 2631 PN6 Weld Neck Flanges at Best Price
DIN 2631 PN6 Welding Neck FF Flange Supplier	Suppliers of DIN 2631 PN6 Weld Neck Flange
German Standard DIN 2631 PN6 Weld Neck Flanges	DIN 2631 PN6 Weld Neck Flange Supplier in Nigeria
DIN 2631 PN6 Weld Neck Flange Manufacturer	Flat Face DIN 2631 PN6 Weld Neck Flange Manufacturer
DIN 2631 PN6 WNRF Flange Stockist in Nigeria	Raised Faced DIN 2631 PN6 welding-neck flanges Dealer in Nigeria
Stainless Steel DIN 2631 PN6 Weld Neck Flange	ASTM B564 Raised Faced DIN 2631 PN6 Weld Neck Flanges
DIN 2631 PN6 WNRF Flange Exporter	DIN 2631 PN6 Weld Neck Flange Pressure Ratings
Raised Face DIN 2631 PN6 Weld Neck Plate Flanges	Titanium DIN 2631 PN6 Welding Neck Flanges
DIN 2631 PN6 WNRF Flanges Supplier in Lagos	Alloy Steel DIN 2631 PN6 Weld Neck Flanges Manufacturer in Nigeria
DIN 2631 PN6 Weld Neck Pipe Flanges Supplier in Ibadan	Duplex Steel DIN 2631 PN6 Weld Neck Flanges
4 inch Stainless Steel DIN 2631 PN6 Weld Neck Flange	DIN 2631 PN6 Weld Neck RF Flanges Stockholder
DIN 2631 PN6 Welding Neck Flanges Supplier in Abuja	MS DIN 2631 PN6 Weld Neck Flange
30 inch DIN 2631 PN6 Weld Neck Flange Dealer	Raised Face DIN 2631 PN6 Weld Neck Flanges Manufacturer
8 Inch DIN 2631 PN6 Welding Neck Pipe Flanges	DIN 2631 PN6 Weld Neck Flanges Stockist
Carbon Steel Raised Face DIN 2631 PN6 Weld Neck Flange Stockist	Duplex Steel DIN 2631 PN6 WNRF Flanges Supplier in Abuja
ASME SA105N Raised Faced DIN 2631 PN6 Weld Neck Flanges	18 inch Carbon Steel DIN 2631 PN6 Weld Neck Flange
DIN 2631 PN6 Weld Neck Pipe Flanges Wholesaler	DIN 2631 PN6 WNRF Flanges Supplier
DIN 2631 PN6 Large Diameter Weld Neck Flange	30 Inch DIN 2631 PN6 Weld Neck Pipe Flange Dimensions
DIN 2631 PN6 WNRF Flanges Distributor in Abuja	Flat Face DIN 2631 PN6 Weld Neck Flanges Exporter

Material Testing

We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
